Industrial Automatic Robotic Arm IRB 5500-25 for ABB
Industrial Automatic Robotic Arm IRB 5500-25 for ABB supplier with good price,Industrial Automatic Robotic Arm IRB 5500-25 for ABB factory Industrial Automatic Robotic Arm IRB 5500-25 for ABB manufacturer with good Industrial Automatic Robotic Arm IRB 5500-25 for ABB price
Description
Quick Details
- Condition:
-
New
- Application:
-
Load
- Place of Origin:
-
Shanghai, China
- Brand Name:
-
ABB
- Weight:
-
600kg, 600kg
- Product Name:
-
Industrial Automatic Robotic Arm IRB 5500-25 for ABB
- Usage:
-
For industry
- Type:
-
IRB 5500-25
- Payload:
-
13kg
- After-sales Service Provided:
-
Engineers available to service machinery overseas
- Warranty:
-
one year
Supply Ability
- Supply Ability:
100 Set/Sets per Month”>100 Set/Sets per Month
Packaging & Delivery
- Packaging Details
Packing type: cardboard box/non-fumigation wooden box”>Packing type: cardboard box/non-fumigation wooden box
- Port
Shanghai port”>Shanghai port
{“detailModule.supplyAbility.title”:”Supply Ability”,”detailModule.supplyAbility.quantity”:”Quantity”,”detailModule.supplyAbility.tip”:”If you finish the payment today, your order will ship out within the delivery date.”}
Online Customization
.richtext [data-maya] {
width: 750px;
font-size:14px;
}
Product Description
Industrial Automatic Robot Arm IRB 5500-25 for ABB
IRB 5500-25 – Industrial Robots From ABB Robotics
The Elevated Rail for the IRB 5500-25 reduces cycle times by as much as 10% on Stop & Go automotive paint lines.
Description
The Elevated Rail for the IRB 5500-25 system is one of the most advanced paint solutions available on the market. Ideally suited for both interior and exterior automotive painting as well as other paint applications, the system expands the fl exibility of the IRB 5500-25 FlexPainter, which is the most versatile working envelope of any paint robot.
The Elevated Rail for the IRB 5500-25 system is one of the most advanced paint solutions available on the market. Ideally suited for both interior and exterior automotive painting as well as other paint applications, the system expands the fl exibility of the IRB 5500-25 FlexPainter, which is the most versatile working envelope of any paint robot.
Designed for Stop & Go automotive paint lines, the Elevated Rail for the IRB 5500-25 increases the flexibility on these types of lines and allows for easy repositioning of the robot, guaranteeing an effective backup solution. It is able to accommodate most car body sizes which has the added advantage of potentially reducing the number of robots on a paint line. This added flexibility and the ability to place the robot in an optimal position directly contributes to reducing cycle times by up to 10%.
Reliability
Based on more than 30 years of rail experience, the Elevated Rail for the IRB 5500-25 is the fifth generation of ABB rail systems for automotive paint shops.
The Elevated Rail for the IRB 5500-25, eliminates the need for additional engineering and other costs associated with installing an IRB 5500-25 on a third party rail. The integrated ABB dynamic modelling for all axes lowers energy consumption, increases accuracy and provides a fully synchronized and balanced paint robot motion.
The elevated rail sections (rail elements) are designed to be a self-carrying structure without the need for a beam support under the rail.
To maintain accuracy and prevent deflection only two pillars with up to 4.7meters (center-to-center) are employed with one or two robots on the rail.
RobotStudio®
The Elevated Rail for the IRB 5500-25 is fully supported for offline programming and 100% accurate cycle checks and path accuracy for all components (including the rail).
Features and benefits:
- Extends unique features of IRB 5500-25, such as fully integrated process and motion- control and the special integration into the paint booth
- Supports up to four robots on a single rail
- Two pillar design accommodates most car body length configurations
- Maximum flexibility for use with a variety of applications
- Total height (dog house) 1123 mm
- Numerous manipulator mounting positions on a single trolley design – tilted, upright, inverted
- Protected cable chain – 300 mm cable chain integrated into the rail elements
- Centralized lubrication – track rails and gear rack, and trolley roller
- Automatic calibration sequence on axis 7 – sensor to detect the calibration position; no calibration tooling needed
Packaging & Shipping
We can delivery the cargo to transport company within 3 days upon receiving of the cargos from the plant
Any question, please do not hesitate to contact me.
Our Services
1.Swift delivery
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
Company Information
Xiangjing(Shanghai)M&E Tech. Co., Ltd is subcompany of Dr. Industry Group Co., Ltd, Dr. Industry Robot Tech. Co., Ltd is subcompany of Dr. Industry Group Co., Ltd too, which focus on discrete industrial automation and process industrial automation, and we can design, develop, install, testing, debug industrial robot, its units and related accessories including fixture, transmission device, positioning device and control system, we can provide Welding Robot, Spray Painting Robot, Transfer Robot, and Grinding Robot, we have many reference in automation industry in China. Meanwhile we are agent of KUKA , ABB, Yaskawa industrial robots, and distributor of FUNC industrial robot. we are the important partner of them in the China market, we have more than 7 engineers with rich expericence, who had been worked for ABB or KUKA more than 10 years. meanwhile Dr. Industry Group can provide ABB and KUKA robot training for our customer, there are weeekly training courses.
Our head office is located in Shanghai, we welcome your visit!
Tel: 0086-21 5352 1755 Fax: 0086-21 6890 6876
Mobile: 0086-18752098511
Wechat:18752098511
Web: shxiangjing.en.alibaba.com/www.gongboshi.com
Address:No.668 East Beijing Road, Huangpu District, Shanghai, China
Shanghai Office
Beijing Office
Hunan Province Office
FAQ
Q.How long will you need before delivery?
A:We have many common models in stock, so that we can deliver the goods very soon(less than 3 days).
Q.What is your payment term?
A:Normally T/T 30% in advance, balance to be paid before delivery, We also support the trade assurance,O/A.
Q:What is Trade Assurance?
A:Trade Assurance is a free service by Alibaba.com that’s designed to help create trust between buyers and suppliers. Trade Assurance helps buyers in the event of shipping and quality-related dispute.
Q:Does Trade Assurance charge fees?
A:No. Trade Assurance is free for both buyers and suppliers.
Q:What kind of trade terms can you do?
A:EX-WORKS,FOB,CFR,CIF,etc.
