Description

3604E TRICONEX 3604E OUTPUT MODULE DIGITAL 24VAC 16POINT TMR OPTP
ISO 3604E Triconex Invensys Cards Analog Input Module CPU PARTS
Programmable PLC Communicate MODULES Robots DCS.Each input module
has leg-to-leg isolation and independence within the I/O board to
ensure that a component failure in one leg will not affect the
signal processing in the other two legs. Each of the triplicated
I/O buses communicates with a single, hardware-defined MP and with
one of the triplicated microprocessors on each I/O module. In each
MP, the I/O bus microprocessor reads the data and provides it to
the MP through a dual port RAM interface. Each MP then transfers
and votes on all data over the Tribus.

TRICONEX 3604E
Manufactured by TRICONEX
OUTPUT MODULE DIGITAL 24VAC 16POINT TMR OPTP ISO
Weight: 8.25 lbs

Model Number 3604E
Nominal Voltage 24 VDC
Type TMR, DO
Output Signals 16, non-commoned
Voltage Range 22-45 VDC
Voltage Drop1 < 4V, typical
Frequency Range n/a
Current Ratings, 2A per point
Maximum 10A surge/10 ms
Load Leakage 2 mA maximum
Chassis Leakage n/a
Fuses (on Field 1 per output,
Termination) 2.5A fast-acting
Point Isolation 1,500 VDC
Diagnostic Indicators
On or Off state 1 per point
Module Status PASS, FAULT, ACTIVE
Field Alarm LOAD/FUSE
Color Code Dark blue

8305A
3805E
3601E
3501E
3700
2852
2651
2551
2750
3003
4107
8300
2790
3700A
8101
3005
3601E
3501E
TRICONEX 3701 Analog Input Module, 0 – 10 V,
Differential, DC Coupled, TMR

TRICONEX 3700A Analog Input Module, 0 – 5 V,

Differential, DC coupled, TMR

TRICONEX 3703E Analog Input Module, 0 – 5 V or 0 – 10 V,

Differential, Isolated, TMR

TRICONEX 3704E Analog Input Module, 0 – 5 V or 0 – 10 V,

High-Density, Differential, DC Coupled, TMR

TRICONEX 3706A Non Isolated Thermocouple Module,

Differential, DC Coupled, TMR

TRICONEX 3708E Isolated Thermocouple Module, Differential, TMR

TRICONEX 3806E Analog Output Module, 4 – 20 & 16 – 320 mA,

Current Loop, DC Coupled, TMR

TRICONEX 3805E Analog Output Module, 4 – 20 mA,

Current loop, DC Coupled, TMR

TRICONEX 3501E Digital Input Module, 115 VAC/VDC,

TRICONEX 3501T Opto-Isolated, Non-Commoned, TMR

TRICONEX 3503E Digital Input Module, 24 VAC/VDC,

Commoned in groups of 8, Self-test, TMR

TRICONEX 3505E Digital Input Module, 24 VDC,

Low threshold with self-test, Commoned, TMR

TRICONEX 3564 Digital Input Module, 24 VDC,

Opto-Isolated, Commoned, Single

TRICONEX 3504E Digital Input Module, 24 or 48 VDC,

High density, DC Coupled, TMR

TRICONEX 3502E Digital Input Module, 48 VAC/VDC,

Commoned in groups of 8, Self-test, TMR

}

}

}

3604E TRICONEX OUTPUT DIGITAL 24VAC 16POINT Images
