3601E TRICONEX 3601E OUTPUT MODULE DIGITAL 3601E Triconex Invensys
Cards Analog Input Module CPU PARTS Programmable PLC Communicate
MODULES Robots DCS.Each input module consists of three identical
and independent circuits, called legs, contained on a single input
card. The isolated input on each leg of each input module receives
sensor outputs that are received on a field termination point. The
microprocessor in each leg continually polls the input points, and
constantly updates an input data table in the local memory of each
leg.

Model Number 3601E
Nominal Voltage 115 VAC
Type TMR, DO
Output Signals 16, non-commoned
Voltage Range 80-155 VAC
Voltage Drop1 < 3V, typical
Frequency Range 47-63 Hz
Current Ratings, 2A per point
Maximum 12A surge/cycle
Load Leakage 2 mA maximum @ 60 Hz
Chassis Leakage 4 mA maximum @ 60 Hz
Fuses (on Field 1 per output,
Termination) 3A fast-acting
Point Isolation 1,500 VDC/ 2500 VDC2
Diagnostic Indicators
On or Off state 1 per point
Module Status PASS, FAULT, ACTIVE
Field Alarm LOAD/FUSE
Color Code Green

MFG: TRICONEX, Made in USA
